DALY 4S 12V 30A BMS with NTC Sensor for LifePO4 Battery Pack

DALY BMS 4S 12V LifePO4 PCB Protection Board with Balance Wire and Temperature Sensor for 4 3.2V Cells 12V LiFePO4 Lithium Battery Pack

This is a 4S fixed configuration basically it cannot be used for any other battery pack configurations. Because it is only a lithium iron phosphate battery management system only. As a result that they cannot be used for Li-Ion, Li-Metal or LTO batteries. It is strictly for LiFePo4 battery packs only.Over charge and over discharge protection The LiFePo4 battery pack will stop charge after the single cell voltage reaches 3.7V and stop discharge when its voltage reaches 2.5V.

Temperature Protection:

• In high temperatures the BMS ranges from 70℃ discharging battery protection.
• Meanwhile in low temperatures the BMS ranges up to -20℃ battery protection.
• Short circuit protection:
• When there is a defect or damage to the circuit at same time the BMS will shut down the whole Battery.
• Certifications Approved:
• ISO/ FCC/ RoHS/ PSE and CE APPROVED

Applications:

Solar and RV, Electric bikes and Skateboard including camping boats and Power tools, Lawn moving and household energy storage systems etc.

What you will get:

• 4S LiFePo4 30A rated voltage with 12V BMS
• Balanced wire sense cable (5 Wire sense cable with connector)
• Instruction Manual

Conclusion:

• Most important that it is only a waterproof BMS available in lithium industry.
• This BMS is also for all kinds of lithium-ion cells including 18650 ,21700, 36500 cylindrical cells and prismatic cells.

Package Includes:

• 1 x 4S 12V 30A LifePo4 BMS
• 1 x Connecting Cable
